Kodiak 1200 Wood Freestanding Stove


 Features

  • Side air damper rod stays cool to the touch.
  • Single, easy-to-use draft control to easily regulate fire.
  • Twin pilot-injector ports for easy start up.
  • Ultra strong air wash to keep glass clean.
  • 3 x 1" 304 grade stainless steel secondary air tubes.
  • Brick-lined firebox with 6" flute.
  • Ceramic top baffle.
  • Mobile home approved.
  • Heavy-duty construction weighing up to 400 lbs.
  • 5/16" thick steel top and ash shelf on flat top models.
  • 1/2" diameter door handle and hinge pins.
  • Cast iron adjustable door latch.

 Options

  • Step Top or Flat Top Body Style.
  • Pedestal Base with Standard Ash Pan.
  • Cast Iron Legs in Painted, Gold or Nickel with Standard Ash Pan.
  • Cast Iron Door in Painted, Gold or Nickel Finish and Painted Door with Gold or Nickel Trim.
  • 135 CFM Fan Kit with Variable Speed Control.
  • "Heat Efficiency Shield" Convection Air Scoop for Flat Top Models.
  • Fresh Air Kit for Airtight Homes.



Specifications

Heating Area

2,200 ft²

BTU's

67,000

Efficiency

82.6%

Glass Size

177 in²

Convection Fan

Optional

EPA Emissions

3.3 gms

Log Size

18”

Burn Time

6-10 hrs

Firebox Size

1.85 ft³

Weight

280 lbs

Flat Top Dims

25” W x 28” H x 23” D

Step Top Dims

25” W x 31” H x 23” D

Boston 1200 Wood Freestanding Stove


 Features

  • Side air damper rod stays cool to the touch.
  • Single, easy-to-use draft control to easily regulate fire.
  • Dual action door latch is laser cut and chrome plated with a wooden handle.
  • Ultra strong air wash to keep glass clean.
  • 3 x 1" 304 grade stainless steel secondary air tubes.
  • Brick-lined firebox with 6" flute.
  • Ceramic top baffle.
  • Mobile home approved.
  • Heavy-duty construction.
  • 5/16" thick steel top and ash shelf on flat top models.
  • 1/2" diameter door handle and hinge pins.
  • Cast iron adjustable door latch.

 Options

  • Painted Black or Chestnut enamel finish.
  • Cast iron side shelves in Multiple Finishes.
  • 135 CFM Fan Kit with Variable Speed Control.
  • Fresh Air Kit for Airtight Homes.



Specifications

Heating Area

2,200 ft²

BTU's

67,000

Efficiency

82.6%

Glass Size

177 in²

Convection Fan

Optional

EPA Emissions

3.3 gms

Log Size

18”

Burn Time

6-10 hrs

Firebox Size

1.85 ft³

Weight

410 lbs

Unit Dims*

30” W x 31” H x 25” D

Kodiak 1700 Wood Freestanding Stove


 Features

  • Side air damper rod stays cool to the touch.
  • Single, easy-to-use draft control to easily regulate fire.
  • Twin pilot-injector ports for easy start up.
  • Ultra strong air wash to keep glass clean.
  • 3 x 1" 304 grade stainless steel secondary air tubes.
  • Brick-lined firebox with 6" flute.
  • Ceramic top baffle.
  • Mobile home approved.
  • Heavy-duty construction weighing up to 400 lbs.
  • 5/16" thick steel top and ash shelf on flat top models.
  • 1/2" diameter door handle and hinge pins.
  • Cast iron adjustable door latch.

 Options

  • Step Top or Flat Top Body Style.
  • Pedestal Base with Standard Ash Pan.
  • Cast Iron Legs in Painted, Gold or Nickel with Standard Ash Pan.
  • Cast Iron Door in Painted, Gold or Nickel Finish and Painted Door with Gold or Nickel Trim.
  • 135 CFM Fan Kit with Variable Speed Control.
  • "Heat Efficiency Shield" Convection Air Scoop for Flat Top Models.
  • Fresh Air Kit for Airtight Homes.



Specifications

Heating Area

3,000 ft²

BTU's

74,000

Efficiency

84.7%

Glass Size

177 in²

Convection Fan

Optional

EPA Emissions

4.5 gms

Log Size

20”

Burn Time

8-12 hrs

Firebox Size

2.5 ft³

Weight

320 lbs

Flat Top Dims

25” W x 28” H x 27” D

Step Top Dims

25” W x 31” H x 27” D

Boston 1700 Wood Freestanding Stove


 Features

  • Side air damper rod stays cool to the touch.
  • Single, easy-to-use draft control to easily regulate fire.
  • Dual action door latch is laser cut and chrome plated with a wooden handle.
  • Ultra strong air wash to keep glass clean.
  • 3 x 1" 304 grade stainless steel secondary air tubes.
  • Brick-lined firebox with 6" flute.
  • Ceramic top baffle.
  • Mobile home approved.
  • Heavy-duty construction.
  • 5/16" thick steel top and ash shelf on flat top models.
  • 1/2" diameter door handle and hinge pins.
  • Cast iron adjustable door latch.

 Options

  • Painted Black or Chestnut enamel finish.
  • Cast iron side shelves in Multiple Finishes.
  • 135 CFM Fan Kit with Variable Speed Control.
  • Fresh Air Kit for Airtight Homes.

Specifications

Heating Area

3,000 ft²

BTU's

74,000

Efficiency

84.7%

Glass Size

177 in²

Convection Fan

Optional

EPA Emissions

4.5 gms

Log Size

20”

Burn Time

8-12 hrs

Firebox Size

2.5 ft³

Weight

450 lbs

Unit Dims*

30” W x 31” H x 29” D
